QNAP TR-004 - NAS Server
- Prices from £228.99 to £307.89 at 2 shops
- No. 663 of 5,084 in PC components
- USB 3.2 Gen 1 Type-C port* for faster data transfer
- Supports up to four SATA drives for reliable read and write performance
- Disk mode DIP switch to change from Hardware Control and Software Control configurations for setting RAID group
- Lockable hard drive trays to prevent accidental drive removal
- Eject button for disconnecting the TR-004 from a NAS or computer
Up to £78.90 cheaper than the most expensive shop
It has not been cheaper in the last 90 days. On average it cost £228.99.
2 offers compared
Sorted by total price including delivery-
£228.99Go to shop: PCHUB.UK -
£307.89Go to shop: Quzo UK
Prices include VAT, last checked 18 October at 12:17. Prices may have changed since. Advertising: some shops pay Pricuro a commission when you buy through a link. Offers are ordered by total price only; used and refurbished offers come last.
Price history
- Now
- £228.99
- Lowest
- £228.99
- Average
- £228.99
- Highest
- £228.99
Product details
| Brand | QNAP |
|---|---|
| Category | PC components |
| Barcode (EAN) | 4713213514429 |
| Shops compared | 2 |
| Price range | £228.99 – £307.89 |
| Total | Lowest total price including delivery: £307.89 |
| On Pricuro since | 3 October 2026 |
Storage
5
| Number of storage drives supported | 4 |
|---|---|
| Storage drive size | 2.5/3.5" |
| Supported storage drive interfaces | Serial ATA II, Serial ATA III |
| RAID levels | 0, 1, 5, 10, JBOD |
| Hot-swap | Yes |
Ports & interfaces
6
| USB connectivity | Yes |
|---|---|
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| USB connector type | USB Type-C |
| USB connector gender | Female |
| USB ports quantity | 1 |
| DC-in jack | Yes |
Design
8
| Product type | HDD/SSD enclosure |
|---|---|
| Product colour | Black |
| LED indicators | HDD, SSD, Status, USB |
| On/off switch | Yes |
| Key lock | Yes |
| Number of fans | 1 fan(s) |
| Fan diameter | 12 cm |
| Number of 3.5" bays | 4 |
Performance
4
| Data transfer rate | 3 Gbit/s |
|---|---|
| Supported file systems | NTFS, ext3, HFS+, exFAT, ext4 |
| S.M.A.R.T. support | Yes |
| Country of origin | Taiwan |
Power
3
| Power source type | DC |
|---|---|
| External power adapter | Yes |
| AC adapter input voltage | 100 - 240 V |
System requirements
2
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows 8.1 |
|---|---|
| Linux operating systems supported | Yes |
Operational conditions
3
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 5 - 95% |
Weight & dimensions
8
| Width | 160 mm |
|---|---|
| Depth | 219 mm |
| Height | 168.5 mm |
| Weight | 3.18 kg |
| Package width | 307 mm |
| Package depth | 520 mm |
| Package height | 320 mm |
| Package weight | 3.18 kg |
Packaging content
7
| Package type | Box |
|---|---|
| Number of keys included | 2 pc(s) |
| AC adapter included | Yes |
| Cables included | AC, USB Type-A to USB Type-C |
| Screws included | Yes |
| Manual | Yes |
| Quick installation guide | Yes |
Other features
1
| Host interface | 1 x USB 3.2 Gen 1 Type-C |
|---|
Technical details
1
| Warranty period | 2 year(s) |
|---|
Logistics data
1
| Harmonized System (HS) code | 84733080 |
|---|
Manufacturer data: Open Icecat
Product description
The TR-004 USB 3.2 Gen 1 RAID expansion enclosure allows you to expand the capacity of your QNAP NAS and PC. The TR-004 can also be utilized as a DAS (Direct-attached Storage) device, allowing you to directly access its content just by connecting it via USB. The TR-004 features four 3.5-inch SATA drive bays with multiple RAID configuration options and USB 3.2 Gen 1 Type-C connectivity to bring you a highly reliable and secure storage capacity expansion solution.
Effective storage expansion with RAID Support
The TR-004 is an ideal storage expansion solution for PCs, especially for laptops…
Read more
The TR-004 USB 3.2 Gen 1 RAID expansion enclosure allows you to expand the capacity of your QNAP NAS and PC. The TR-004 can also be utilized as a DAS (Direct-attached Storage) device, allowing you to directly access its content just by connecting it via USB. The TR-004 features four 3.5-inch SATA drive bays with multiple RAID configuration options and USB 3.2 Gen 1 Type-C connectivity to bring you a highly reliable and secure storage capacity expansion solution.
Effective storage expansion with RAID Support
The TR-004 is an ideal storage expansion solution for PCs, especially for laptops which lack the ability to install larger, higher-capacity drives. Featuring four 3.5-inch SATA drive bays and supporting RAID configuration, the TR-004 provides the ability to store a vast number of files and data and to ensure protection against potential drive failure.
Supports various RAID levels
The TR-004 supports a variety of RAID configurations. Depending on your requirements, you can switch between hardware- or software-controlled RAID modes. Move the DIP switches to corresponding positions for your ideal RAID mode: Individual, JBOD, RAID 0, RAID 1/10 or RAID 5. You can also configure the RAID settings from your QNAP NAS, or by using the QNAP External RAID Manager utility on your computer.
Flexible storage configuration and management
Compared with other RAID enclosures, the TR-004 provides software-controlled configurations for greater management flexibility. Users can configure RAID and monitor disk health using Storage & Snapshots Manager on a QNAP NAS, or by using the QNAP External RAID Manager utility on their computer.
Versatile usage scenarios to meet storage expansion needs
The TR-004 meets many storage expansion requirements for home and work use, including:
Scenario 1: Expand the capacity of your NAS
The TR-004 provides an alternative method for users to expand their NAS storage capacity. By connecting the TR-004 to their NAS and using the Storage & Snapshots Manager, users can easily configure and manage their storage expansion. The TR-004 supports a variety of QNAP NAS storage and file management functions, allowing users to build storage pools, find files with Qsirch and organize files with Qfiling.
Use the TR-004 as an alternative to conventional NAS expansion enclosures
As an external hardware RAID device, the TR-004 operates independently and does not require additional NAS system resources. When compared with the UX-500P expansion enclosure, the TR-004 uses less NAS system resources.
Scenario 2: External storage for your NAS
Instead of using the TR-004 to expand the capacity of your QNAP NAS, you can use it as a complimentary storage unit for backing up or moving data. It also allows you to physically migrate huge data collections that would require significant network bandwidth. While connected to the NAS, you can monitor the health and status of the TR-004 by using the Storage & Snapshots Manager on the NAS.
Scena
Frequently asked questions
Where is QNAP TR-004 - NAS Server cheapest?
Right now at PCHUB.UK for £228.99. We compare 2 offers.
How much does QNAP TR-004 - NAS Server cost?
Prices range from £228.99 to £307.89. Over the last 90 days it cost £228.99 on average.
Is now a good time to buy QNAP TR-004 - NAS Server?
Lowest price in 90 days. It has not been cheaper in the last 90 days. On average it cost £228.99.
Is QNAP TR-004 - NAS Server in stock?
Yes, 2 shops list it as in stock.
